Z10 PRO TECHNICAL SPECS
Specifications
- Output Resolution: 4K (3840 x 2160)
- CPU : Realtek RTD1319
- GPU : ARM G31 MP2
- RAM: 4GB DDR4 @2400MHz
- Storage: 32GB eMMC
- Operating System : Android 10
_________________________________________________________________________________________________________________________________
Networking
- Wireless : Dual-Band 2×2 AC Wireless
- BT : 5.0
- Ethernet : 1000M (Gigabit)
_________________________________________________________________________________________________________________________________
Decoder
- Video decoder : 4K@60fps, AV1, H.265(HEVC), AVS, H.264(AVC, MVC), Real, MPEG1/2/4, VC-1
- Audio decoder : MPEG-1 Layer 1,2,3(2-CH), MPEG-2 Layer 1,2, HE AAC V1/V2
- Support Language: Global
- DRM : Widevine L1, L3
_________________________________________________________________________________________________________________________________
Dimensions
- Length: 105mm
- Width: 105mm
- Thickness: 21mm
- Color: Black
_________________________________________________________________________________________________________________________________
Ports
- Power Input : 1
- USB3.0 : 1
- USB2.0 : 1
- HDMI : 1
- Gigabit LAN : 1
- Micro SD Card : 1
- IR Extension : 1
_________________________________________________________________________________________________________________________________
Power input
- Power rating : 12VDC / 1A
- Power Consumption : Max. 12W
- Standby Power : Max. 0.5W (Ultra low power)
_________________________________________________________________________________________________________________________________
Optional
ATSC USB Tuners:
– Hauppauge WinTV-HVR-955Q (2040:b123)
– Hauppauge WinTV-HVR-955Q (2040:b150)
– Hauppauge WinTV-dualHD (2040:026d)
DVB-T USB Tuners:
– Hauppauge WinTV-dualHD (2040:8265)
– Geniatech MyGica T230 Black (0572:689A)
– Geniatech OEM T230 White (0572:c68a)
– Xbox One Digital TV Tuner (045E:02D5)
