MAG544 | MAG544w3

$139.99



High-performance 4K set-top boxes powered by the ARM Cortex-A35 CPU

The MAG544 and MAG544w3 are Infomir’s IPTV set-top boxes powered by Linux OS. These devices come with the Amlogic S905Y4 chipset and quad-core ARM Cortex-A35 CPU. They play video stably and smoothly in all modern formats, including 4K.

Their hardware enables operators to provide comfortable and reliable services to their customers, and the continuity of the UI ensures easy integration into projects that use MAG devices.

Add to Wishlist
Add to Wishlist

MAG540w3 Linux set-top box with built-in Wi-Fi module

With the MAG540w3, you can watch your favorite movies in high resolution without any stuttering or frequent reboots. The set-top box features a high-performance Amlogic S905Y4 SoC with four ARM Cortex-A35 cores, meaning it will run for months without rebooting.

The MAG540w3 supports 4K video, so you can watch hi-res content with a stunning picture. The crystal-clear volumetric sound enhances the experience. Connect the device to a modern TV or audio system, and you will be blown away by the eight-channel Dolby Digital Plus™ sound. With H.256 codec, the set-top box works smoothly and stutter-free, even at lower Internet connection speeds.

The device has two USB ports for your mouse, keyboard, or external storage. You can also easily hook it up to the Internet: with a wire via Ethernet or wirelessly over Wi-Fi. The set-top box features the classic Qubic design that will look at home in any interior.

Technology for the best user experience

  • 4K and HEVC support
  • 1 GB RAM
  • 4 GB eMMC
  • Wi-Fi
  • Quad-core ARM Cortex-A35
  • User-friendly IR remote

MAG520w3 specifications

Audio and video

  • Video modesPAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p (4K)
  • Audio codecsMPEG L1/L2/L3l, AAC-LC, HE AAC V1/V2, APE, FLAC, Dolby Digital Plus™
  • Audio formatsMP3, OGG, WAV, AAC
  • Video codecsMPEG1/2 MP@HL, MPEG4 part 2 (ASP), H.265 Main/Main 10@L5.1 High 2160p@60 fps (optional), H.264 AVC High@L5.1 2160p@30 fps, XviD, AV1, 3D video support
  • Video containersTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB
  • Image formatsJPEG, PNG, BMP, RAW
  • SubtitlesDVB, PGS, SRT, SSA/ASS, SUB, Teletext, WebVtt, closed captions
  • Playlist formatsM3U, M3U8, PLS, CUE

Hardware features

  • ChipsetAmlogic S905Y4-B
  • Performance16,500 DMIPS
  • CPUQuad-core ARM Cortex-A35
  • RAM1 GB DDR3
  • Storage4 GB eMMC

Software and CAS/DRM

  • OSLinux 4.9
  • DRM/CASOn request
  • MiddlewarePre-integrated Ministra TV platform. We can integrate the operator’s applications into the image and customize or replace the image.

Interfaces

  • Digital portsHDMI 2.1
  • Ethernet100 Mbps
  • USB2 × USB 2.0
  • Bluetooth
  • Wi-FiBuilt-in 2T2R ac

Power

  • Power supply unitDC 5 V, 2 A

Dimensions

  • Width/depth/height120 × 78 × 21 mm
  • Weight110 g
